Unleash the Power of High-Voltage Performance with MCC’s IGBT PIM Solutions

Compact yet powerful, MCC’s IGBT PIMs pack quite a punch. These components integrate multiple power-switching devices into a single package. Choose from E1, E1A, and E2A to get the job done with greater control in a streamlined design.

Our IGBT PIMs enable engineers to maximize power delivery while reducing overall size and costs for components and heat sinks. Made for easy mounting and installation, these modules are in demand for high-power Industrial applications.

1200V IGBT E1 E2A E1A MCC
Features & Benefits:
  • Trench IGBT technology
  • Three-Phase Input Rectifier Topology
  • Isolated heat sink using DBC technology
  • Low switching loss
  • Fast & soft recovery anti-parallel FWD
  • High short circuit ruggedness
  • Positive temperature coefficient for easy paralleling

Transform Your Designs with Advanced PIM Technology + Three-Phase Input Rectifier Topology

1200V IGBT PIM

1

Multi-device switching in One Package

Multiple power switching devices integrated into a single package (E1, E1A, E2A) for high-power density in a smaller design.

1200V IGBT PIM

2

Streamlined Footprint Drives Cost Savings

Compact size decreases heat sink costs and component footprint to optimize power and overall design.

1200V IGBT PIM

3

Modular Design Simplifies Installation

Modular component design facilities simple installation and replacement with surface-mount technology (SMT).

1200V IGBT PIM

4

Ideal for high-power, fast switching

Enables fast switching capability while delivering high power in a small form factor for greater control of output voltage and current.

Applications:

Industrial Automation IGBT applications MCC Renewable Energy IGBT applications MCC Power Electronics IGBT applications MCC
Industrial Automation Renewable Energy Power Electronics
  • Motor driver
  • Power supplies/inverters
  • Electric compressors & heaters
  • Motor control circuits
  • Welding machines
  • Wind turbines
  • Photovoltaic/solar inverters
  • Energy storage systems (ESS)
  • UPS (uninterruptible power supply)
  • Power factor correction
  • Power supplies, including telecom and data center equipment



Product Attributes, Parametrics, Datasheet:


Product

Voltage Current

Power

Device Package Vce (on) Mounting Type

Info/Data Sheet

MIP25R12E1TN-BP 1200V 25A 166W Module E1 2.25V @15V, 25A Chassis Mount info
MIP50R12E1ATN-BP 1200V 50A 288W Module E1A 2.3V @15V, 50A Chassis Mount info
MIP50R12E2ATN-BP 1200V 50A 288W Module E2A 2.3V @ 15V, 50A Chassis Mount info
MIP75R12E2ATN-BP 1200V 75A 476W Module E2A 2.15V @ 15V, 75A Chassis Mount Info



Use the MCC website chatbot to learn more about these innovative high-power IGBT PIMs or request a sample.
